Product Details:
|
| Warranty: | 1 Year | Cycle Life: | 20000 Times |
|---|---|---|---|
| Product Name: | 48V3900WH Telecom Battery Systems Telecommunication Battery 48v Deep Cycle Battery | Battery Type: | 4.2V21000F Super Capacitor Battery Cell |
| Weight: | 27KGS | Color: | Customized/Silver |
| Nominal Capacity (ah): | 3900WH | Bms: | BMS |
| Battery Cell: | Super Capacitor Battery Cells | Oem/odm: | Available |
| Rated Voltage: | 48VDC | Operating Temperature: | -40 To +70 ℃ |
| Lead Time: | 7days After Payment | Shipment Method: | Express/air/sea |
| High Light: | BMS Telecom Battery Backup Systems,Multiscene Telecom Battery Backup Systems |
||
Product Description
| Product Name | GH 48V 3900Wh Moudle |
| Serial parallel mode | 13S4P |
| Rated Capacitance | 6500F |
| Energy Storage | 3900Wh |
| Rated Voltage | 48V |
| Maximum Charge Voltage | 54.6V |
| Minimum Discharge Voltage | 35.2 V |
| Internal Resistance(AC) | ≤ 10 mOhm |
| Rated Current | 80A |
| Maximum Continuous Current | 160A |
| Max. Peak Current | 240A |
| Safety Test | DC1500V |
| Operating Temperature Range | minus 20 to plus 60 ℃ |
| Storage Temperature Range | minus 20 to plus 55 ℃ |
| Cycle life | ≥ 20,000 |
| Protection Class | IP30 |
| Product Weight | 27kg |
| Product Size ±5mm | 420x400x160mm |
| Warranty Time | 5 years |
