Product Details:
|
| Features: | Ultraportable | Type: | Li-Ion,LiFePo4,lifepo4/lithium Battery/li-ion Battery |
|---|---|---|---|
| Nominal Voltage: | 48V | Nominal Capacity: | 2.4Kwh/5.12Kwh/10.24Kwh/12.80Kwh |
| Application: | Solar System/RV/yacht/golf Carts Storage And Car/UPS | Size: | Customized, 482*410*89mm/482*400*177mm/482*430*222mm/482*500*280mm |
| Cycle Life: | >6000Cycles | Warranty: | 5 Years |
| Color: | Black(customize) | Weight: | 24KG/46KG/80KG/100KG |
| Battery Type: | LiFePo4 | Oem/odm: | Accepatable,Yes |
| Shape: | Square-shaped | Capacity: | 50ah/100ah/200ah/250sh,customized |
| Compact Desiged: | With Built-in BMS | Battery Capacity: | With LED Indicator |
| Trasportation: | By Sea/By Air/By Express | ||
| High Light: | Ultraportable BMS Battery Management System,200ah BMS Battery Management System,Lifepo4 Battery With BMS |
||
Model | GH2400 | GH5000 | GH9600 | GH12000 |
Voltage | 48 V | 48 V | 48 V | 48 V |
Capacity | 50Ah | 100Ah | 200Ah | 250Ah |
Energy | 2.4Kwh | 5.12Kwh | 10.24Kwh | 12.80Kwh |
Operation voltage | 35.25-54.75 Vdc | 37.6-58.4Vdc | ||
Max.charging voltage | 54.75Vdc | 58.4 Vdc | ||
Max.charging and discharging current | 50A | 100A | ||
Max Power | 2400W | 5120W | 7680W | 12800W |
Life time(25°C) | 10 years | |||
Life cycles(80% DOD, 25°C) | 6000 Cycles | |||
Enclosure protection rating | IP65 | |||
Dimensions(L×W×H)mm | 482*410*89 | 482*400*177 | 482*430*222 | 482*500*280 |
Weight | 24KG | 46KG | 80KG | 100KG |
Lithium Battery Standard | UL,IEC, UN38.3, ROHS,CE | |||
Support ODM, OEM customization
