Product Details:
|
| Type: | Super Capacitor | Place Of Origin: | GUANGDONG ,China |
|---|---|---|---|
| Media Available: | Datasheet,photo | Package Type: | Through Hole |
| Operating Temperature: | -40℃ To 65℃ | Current-leakage: | 1mA |
| Warranty: | 5 Years | Package: | Cartons |
| Cycle Life: | More Than 100000 Times | Size: | 62*35mm |
| High Light: | IP30 super capacitor battery for solar,470F super capacitor battery for solar,0.45Wh High Power battery |
||
High Power Super Capacitor Cells Specification 2.7V 470F Φ35*62 mm
Supercapacitors are constructed with two metal foils (current collectors), each coated with an electrode material such as activated carbon, which serve as the power connection between the electrode material and the external terminals of the capacitor. Specifically to the electrode material is a very large surface area. In this example the activated carbon is electrochemically etched, so that the surface area of the material is about 100,000 times greater than the smooth surface. The electrodes are kept apart by an ion-permeable membrane (separator) used as an insulator to protect the electrodes against short circuits. This construction is subsequently rolled or folded into a cylindrical or rectangular shape and can be stacked in an aluminum can or an adaptable rectangular housing. The cell is then impregnated with a liquid or viscous electrolyte of organic or aqueous type. The electrolyte, an ionic conductor, enters the pores of the electrodes and serves as the conductive connection between the electrodes across the separator. Finally, the housing is hermetically sealed to ensure stable behavior over the specified lifetime.
Electric propelling applications:
Automotive energy system; low speed vehicle; intelligent robot; electric bicycle / motorcycle / scooter;golf cart / trolley / sightseeing car /; electric tools
Back-up system and UPs:
Telecom base,CATV-system, computer server center, medical instrument, military equipment.
Other applications:
Security and electronics; mobile POS, mining light/torch/LED light emergency light.
Nail Penetration Test: No Explosion, No Fire
Vibration Test: No Explosion, No Fire
Drop Test: No Explosion, No Fire
Crush Test: No Explosion, No Fire
Overcharge Test: No Fire, No Explosion
Over Discharge Test: No Explosion, No Fire
Fast charging
Small self discharge
High safety and reliabitityLow temperature performanceLow long-term cost
Long cycle life
